Hardware, memory & roofline

Why this matters at staff level. "Explain the roofline" is a standard question, and the follow-ups ("where does attention sit?", "why does batch 1 decode waste your GPU?", "why does padding a dimension to 64 speed it up?") separate people who have read about GPUs from people who have profiled them. This chapter is the physical substrate under the other three: every memory, parallelism and serving decision in Part XIV reduces to bytes moved versus FLOPs done.

TL;DR: the interview card

  • Roofline: attainable \(= \min(F_\text{peak},\; I \cdot BW)\) where \(I\) = FLOPs / bytes moved. The ridge point \(I^\star = F_\text{peak}/BW\) divides memory-bound (left) from compute-bound (right).
  • H100 SXM: 989 TFLOP/s dense BF16 (tensor cores), 3.35 TB/s HBM3, 80 GB → ridge ≈ 295 FLOP/byte. A100 80 GB SXM: 312 TFLOP/s BF16, 2.04 TB/s HBM2e (2,039 GB/s on the datasheet, taken as 2.0 below) → ridge ≈ 156.
  • Memory hierarchy (per GPU, orders of magnitude): registers ~10s TB/s → SMEM/L1 ~10 TB/s → L2 (tens of MB) ~several TB/s → HBM (80 GB) 2–3.4 TB/s → NVLink ~450 GB/s/direction → PCIe 5.0 x16 ~64 GB/s → InfiniBand NDR 50 GB/s/port. Each step down is ~an order of magnitude.
  • Kernel intensities: big matmul \(10^3\); FlashAttention ~\(10^3\); naive attention ~60 (it writes and re-reads the \(T\times T\) matrix); LayerNorm ~2; decode step = batch size.
  • FLOPs accounting: forward \(\approx 2N\) per token \(+\,4Lhs\) for attention; training \(3\times\) that.
  • Bytes/param: fp32 4, bf16/fp16 2, fp8 1, int4 0.5. Training state with Adam = 16 B/param.
  • Fusion is the main lever left of the ridge: fusing \(n\) elementwise ops turns \(n\) HBM round-trips into one. FlashAttention is fusion + tiling + online softmax.
  • Tensor cores want shapes that are multiples of 8 (fp16/bf16) and ideally 64/128 on the GEMM's M/N/K; odd vocab sizes and head dims leave 20–50 % on the table.
  • CUDA graphs remove per-kernel launch overhead (~5–10 µs each), which dominates small-batch decode where each layer's kernels take microseconds.

1. Intuition first

Every kernel is a deal between two resources: the machine can do \(F_\text{peak}\) FLOPs per second and move \(BW\) bytes per second. A kernel that does \(\Phi\) FLOPs while moving \(M\) bytes cannot finish faster than

\[ t \ge \max\left(\frac{\Phi}{F_\text{peak}},\ \frac{M}{BW}\right) \]

Which term wins depends only on the ratio \(I = \Phi / M\), the arithmetic intensity. Take three kernels on one H100, all on bf16 data:

Kernel FLOPs HBM bytes \(I\) Bound by
\(y = x + 1\) on \(10^9\) elements \(10^9\) \(4\times10^9\) (read + write) 0.25 memory, by 1000×
\((8192\times4096) @ (4096\times4096)\) \(2.7\times10^{11}\) \(1.7\times10^8\) 1638 compute
decode step, 7B, batch 1 \(1.4\times10^{10}\) \(1.4\times10^{10}\) 1.0 memory, by 295×

The elementwise kernel and the batch-1 decode are the same kind of problem: they read a lot and compute little. No amount of tensor-core capability helps; the only fixes are to move fewer bytes (fusion, quantisation, keeping data in SRAM) or to do more work per byte (batching). That single observation explains FlashAttention, kernel fusion, quantisation for serving, and why batch-1 LLM inference "wastes" a $30{,}000 GPU.

A useful mental image: the GPU is a factory with an enormous assembly line (tensor cores) fed by a single narrow loading dock (HBM). The ridge point is the ratio at which the dock can just keep the line busy. Everything in this chapter is either "how big is the line", "how wide is the dock", or "how do I avoid going through the dock at all".

Roofline with kernels placed

The H100 roofline with real LLM kernels placed on it. Prefill matmuls and FlashAttention sit on the flat (compute-bound) roof; LayerNorm, naive attention and batch-1 decode sit on the slanted (memory-bound) part. Note that naive and Flash attention do identical FLOPs, the only difference is bytes moved, which moves the kernel 30× to the right.

2. The math

2.1 The roofline model and the ridge point

Williams, Waterman and Patterson (2009) proposed plotting attainable performance against arithmetic intensity on log-log axes:

\[ \boxed{\;P(I) = \min\big(F_\text{peak},\; I \cdot BW\big),\qquad I^\star = \frac{F_\text{peak}}{BW}\;} \]

For \(I < I^\star\) the kernel rides the diagonal \(I\cdot BW\) and its performance is set entirely by bandwidth; for \(I > I^\star\) it is flat at \(F_\text{peak}\). Two consequences interviewers look for:

  1. Optimising FLOPs in a memory-bound kernel does nothing. Halving the arithmetic of a LayerNorm changes \(I\) from 2 to 1 and the runtime not at all.
  2. Moving right is the goal. You move right by increasing reuse (batching, tiling, fusion), never by adding FLOPs.

The ridge is a property of the machine, and it has been getting worse for decades: compute has grown faster than bandwidth, so \(I^\star\) has climbed (V100 ~139, A100 ~156, H100 ~295 in bf16). More and more kernels fall to the left of it over time. This is the "memory wall", and it is why so much recent ML systems work is really data-movement work.

2.2 Computing intensity for the kernels that matter

Matmul \((M,K)\times(K,N)\), 2 bytes per element, everything read once from HBM:

\[ I = \frac{2MNK}{2(MK + KN + MN)} \]

With \(M=N=K=n\) this is \(n/3\): intensity grows linearly with the matrix size, which is why big matmuls are the easiest thing to make fast. With \(M = 1\) (a matrix-vector product, i.e. batch-1 decode) it collapses to \(\approx 1\) regardless of \(K, N\). The shape, not the operation, decides.

Attention, single head, sequence \(T\), head dim \(d\). FLOPs are \(\approx 4T^2d\) for the two matmuls. Naive implementations write the \(T\times T\) score matrix to HBM, read it back for softmax, write the probabilities, and read them for \(PV\):

\[ I_\text{naive} = \frac{4T^2d + 5T^2}{2(3Td + 4T^2 + Td)} \xrightarrow{T \gg d} \approx \frac{4T^2d}{8T^2} = \frac{d}{2} \]

That limit is about 60 FLOP/byte at \(d=128\), far below the ridge. FlashAttention never materialises the score matrix: it tiles \(Q, K, V\) into SRAM-sized blocks and keeps a running softmax, so HBM traffic is just \(Q, K, V, O\):

\[ I_\text{flash} \approx \frac{4T^2d}{2 \cdot 4Td} = \frac{T}{2} \]

At \(T = 4096, d = 128\) the computed values are \(I_\text{naive} = 62.7\) and \(I_\text{flash} = 2068\): 33× more intensity for identical arithmetic, which is why the same FLOPs take 41 µs vs 8.8 µs on the H100 roofline. The derivation, the online-softmax recurrence and the IO-complexity bound are in efficient attention & KV cache; the point here is only where it sits on the roofline and why.

Decode step of a \(P\)-parameter model at batch \(B\): \(2PB\) FLOPs, \(wP\) bytes of weights, so \(I = 2B/w = B\) in bf16. The arithmetic intensity of LLM decoding is the batch size. That one sentence answers half the inference-systems questions in the previous chapter.

LayerNorm/RMSNorm on \(n\) elements: ~8 FLOPs per element, 2 accesses (read \(x\), write \(y\)) at 2 bytes → \(I = 8n/(4n) = 2\). Norms are pure bandwidth, which is why they get fused into their neighbours.

2.3 FLOPs and bytes accounting

\[ \boxed{\;F_\text{fwd/token} \approx 2N + 4Lhs,\qquad F_\text{train/token} \approx 6N + 12Lhs\;} \]

The \(2N\) is one multiply and one add per weight element; \(4Lhs\) covers \(QK^\top\) and \(PV\) (each \(2sh\) per token per layer). Causal masking halves the useful work but the convention (PaLM, Megatron) counts the full term. Say which convention you are using when you quote MFU.

\[ \begin{array}{lcccc} \textbf{dtype} & \text{fp32} & \text{bf16/fp16} & \text{fp8} & \text{int4}\\ \textbf{bytes/param} & 4 & 2 & 1 & 0.5 \end{array} \]

Multiply by the count to get weights; add 16 B/param of training state for training, or \(2Ln_{kv}d_\text{head}w\) bytes per token of KV for serving.

2.4 The memory hierarchy, and why locality is everything

Level Size (H100 class) Bandwidth (order) Latency (order)
Registers 256 KB per SM ~10s TB/s ~1 cycle
Shared memory / L1 ~228 KB per SM ~10 TB/s aggregate ~20–30 cycles
L2 ~50 MB several TB/s ~200 cycles
HBM3 80 GB 3.35 TB/s ~400–600 cycles
NVLink 4 (to peer GPU) : ~450 GB/s per direction (900 GB/s aggregate) ~µs
PCIe 5.0 x16 (to host) : ~64 GB/s per direction ~µs
InfiniBand NDR (to another node) : 50 GB/s per 400 Gb/s port ~µs+

Two engineering rules follow. (1) A tile that fits in SRAM can be reused many times at ~10 TB/s instead of 3.35 TB/s; every fast matmul and FlashAttention kernel is organised around this. (2) Host↔device transfers are ~50× slower than HBM, so they must be (a) rare, (b) on pinned (page-locked) memory, which lets the DMA engine copy without staging through a pageable bounce buffer and lets the copy overlap compute on a separate stream, and (c) issued asynchronously. An unpinned .to("cuda") in the training loop is a synchronous stall.

2.5 GPU and TPU architecture, briefly but concretely

A GPU is an array of streaming multiprocessors (H100 SXM: 132 SMs). Each SM has warp schedulers issuing instructions for warps of 32 threads in lockstep, a register file, shared memory, CUDA cores (scalar FP32/INT) and tensor cores (fixed-function matrix-multiply-accumulate units operating on small tiles, e.g. 16×8×16 for bf16). Nearly all of the advertised TFLOP/s is tensor-core throughput: CUDA-core FP32 on an H100 is ~67 TFLOP/s, about 1/15 of the BF16 tensor number. If your kernel is not hitting tensor cores, you are working with 7 % of the machine.

Consequences for shapes: tensor cores consume fixed tiles, and the library (cuBLAS/CUTLASS) decomposes a GEMM into tiles of typically 64–256 per dimension across SMs. So:

  • Dimensions that are multiples of 8 are required to use the fp16/bf16 tensor-core path at all in cuBLAS; multiples of 64 or 128 avoid partial tiles and ragged tails.
  • A vocabulary of 50,257 is the standard example. Padding it to 50,304 (a multiple of 128) is a measurable speed-up for the LM-head GEMM at zero quality cost.
  • Wave quantisation: if the tiles do not evenly fill the SMs, the last "wave" runs at partial occupancy. A GEMM producing 133 tiles on 132 SMs takes as long as 264 tiles.

A TPU replaces many small SMs with a large systolic array (a 128×128-ish MXU): data flows through a fixed grid of MACs, so weights and activations are reused spatially and the design is extremely efficient when the matrices fill the array. The practical consequence is the same rule with sharper teeth: shapes should be multiples of the MXU dimension (128) and of the batch tiling (8), or you pad and waste. TPU pods connect chips with a dedicated ICI torus fabric rather than PCIe/IB, which is why Google's large runs can use high model-parallel degrees without pipelining (see PaLM in the distributed-training chapter).

2.6 Fusion, Triton and CUDA graphs

Fusion. A chain like x -> layernorm -> gelu -> dropout -> add executed as four kernels reads and writes HBM four times; fused into one kernel it reads once and writes once. For memory-bound ops the speed-up is close to the number of fused round-trips saved. This is why torch.compile and hand-written kernels win on the "small" ops even though they contain no clever mathematics.

What a tiled matmul kernel looks like (in prose). In Triton you write a program that computes one output tile: each program instance is given a tile index, from which it computes row and column offsets. It allocates an accumulator tile in registers (say 128×128 in fp32), then loops over the K dimension in chunks (say 64): each iteration loads a 128×64 block of \(A\) and a 64×128 block of \(B\) into shared memory with masked loads (so the edges of a non-multiple-of-tile matrix are handled), issues a tensor-core dot into the accumulator, and advances the pointers. After the loop it casts the accumulator to the output dtype and stores the tile with masking. The performance ideas are: keep the accumulator in registers (never touch HBM inside the K loop), stage through shared memory so each loaded element is used by 128 multiply-accumulates, and choose the tile shape so the loop is deep enough to hide the load latency. Everything else (autotuning BLOCK_M/N/K and num_stages, swizzling the tile order for L2 reuse) is tuning. That mental model is what "Triton literacy" means in an interview; you do not need to recite the syntax.

CUDA graphs. Each kernel launch costs a few microseconds of CPU-side work. A 32-layer model's decode step is hundreds of tiny kernels, each running for a few microseconds, so launch overhead can exceed the GPU work. A CUDA graph records the whole step once and replays it as a single submission, removing per-launch overhead and CPU jitter. The constraints are the point: shapes and pointers must be static, which is exactly why serving engines pad to a set of fixed batch sizes and pre-allocate KV blocks.

3. Implementation

3.1 Roofline calculator and plot

@dataclass(frozen=True)
class Machine:
    name: str
    peak_flops: float
    bandwidth: float

    @property
    def ridge_point(self) -> float:
        return self.peak_flops / self.bandwidth          # FLOP per byte

    def attainable(self, intensity: float) -> float:
        return min(self.peak_flops, intensity * self.bandwidth)

def matmul_kernel(M, N, K, bytes_per_elem=2.0, name=None):
    flops = 2.0 * M * N * K                              # multiply-accumulate per output element
    moved = bytes_per_elem * (M * K + K * N + M * N)     # A, B read once; C written once
    return Kernel(name or f"matmul {M}x{K}x{N}", flops, moved)

def naive_attention_kernel(T, d, bytes_per_elem=2.0):
    flops = 2.0 * T * T * d * 2 + 5.0 * T * T            # QK^T and PV, plus softmax elementwise
    moved = bytes_per_elem * (3 * T * d + 4 * T * T + T * d)  # Q,K,V in; S out+in, P out+in; O out
    return Kernel(f"naive attention T={T}", flops, moved)

def flash_attention_kernel(T, d, bytes_per_elem=2.0):
    flops = 2.0 * T * T * d * 2 + 5.0 * T * T            # identical arithmetic
    moved = bytes_per_elem * (4 * T * d)                 # the (T, T) tensor never leaves SRAM
    return Kernel(f"flash attention T={T}", flops, moved)

Every kernel constructor encodes one honest byte count. That is the entire content of a roofline analysis, and getting the byte count right is the part people fumble. plot_roofline draws \(\min(F_\text{peak}, I\cdot BW)\) on log-log axes and places each kernel at \((I, \text{attainable}(I))\); the test writes it to a temp file and checks a non-trivial PNG comes out.

time_lower_bound(kernel, machine) returns \(\max(\Phi/F, M/BW)\). Compare that against a profiler trace. If your measured time is 3× the lower bound, you have an occupancy, launch-overhead or shape problem; if it is at the bound, only a different algorithm will help.

3.2 FLOPs/token calculator

def matmul_params(cfg):
    p = count_params(cfg)
    unembed = cfg.vocab * cfg.d_model                    # the LM head is a matmul even if tied
    return p["attention"] + p["mlp"] + unembed           # embedding lookup is a gather, not a matmul

def flops_per_token(cfg, seq_len, mode="train", recompute=False):
    fwd = 2.0 * matmul_params(cfg) + attention_flops_per_token_forward(cfg, seq_len)  # 2N + 4Lhs
    if mode == "forward":
        return fwd
    return (4.0 if recompute else 3.0) * fwd             # bwd = 2x fwd; +1 fwd if recomputing

The subtlety worth stating out loud in an interview: the input embedding is a lookup, so it contributes parameters but no FLOPs, while the LM head is a full GEMM against the vocabulary. For small models with large vocabularies (Llama-3-8B: 128k vocab × 4096) the head is a significant share of both.

Full implementation: src/mlbook/systems/roofline.py
"""The roofline model.

    attainable FLOP/s = min(peak_flops, intensity * bandwidth)
    intensity I = FLOPs / bytes moved (FLOP per byte)
    ridge point I* = peak_flops / bandwidth: kernels left of it are memory-bound.

Kernel intensities (16-bit, 2 bytes per element):
    matmul (M, K) x (K, N): 2 M N K / (2 (M K + K N + M N))
    decode step of an LLM (batch B): 2 P B / (2 P) = B
    elementwise / layernorm on n elements: O(1) FLOP per byte (e.g. ~ 1/2 ... 2)
    naive attention scores (T x T x d): 2 T^2 d / (2 (2 T d + T^2)) ~ d for T >> d ... but
    with the (T, T) probabilities written and re-read the intensity collapses toward ~1.
"""

from __future__ import annotations

from dataclasses import dataclass


@dataclass(frozen=True)
class Machine:
    name: str
    peak_flops: float
    bandwidth: float

    @property
    def ridge_point(self) -> float:
        return self.peak_flops / self.bandwidth

    def attainable(self, intensity: float) -> float:
        return min(self.peak_flops, intensity * self.bandwidth)


H100_SXM = Machine("H100 SXM (BF16 dense, HBM3)", 989e12, 3.35e12)
A100_80GB = Machine("A100 80GB (BF16 dense, HBM2e)", 312e12, 2.0e12)


@dataclass(frozen=True)
class Kernel:
    name: str
    flops: float
    bytes: float

    @property
    def intensity(self) -> float:
        return self.flops / self.bytes


def matmul_kernel(M: int, N: int, K: int, bytes_per_elem: float = 2.0, name: str | None = None) -> Kernel:
    """(M, K) @ (K, N): 2MNK FLOPs; reads A and B once, writes C once."""
    flops = 2.0 * M * N * K
    moved = bytes_per_elem * (M * K + K * N + M * N)
    return Kernel(name or f"matmul {M}x{K}x{N}", flops, moved)


def decode_step_kernel(n_params: float, batch: int, bytes_per_param: float = 2.0) -> Kernel:
    """One decode step: every weight read once, 2 FLOPs per weight per sequence."""
    return Kernel(f"decode B={batch}", 2.0 * n_params * batch, bytes_per_param * n_params)


def layernorm_kernel(n_tokens: int, d: int, bytes_per_elem: float = 2.0) -> Kernel:
    """~ 8 FLOPs per element (mean, var, normalise, scale/shift); read x, write y."""
    n = n_tokens * d
    return Kernel(f"layernorm {n_tokens}x{d}", 8.0 * n, 2.0 * bytes_per_elem * n)


def naive_attention_kernel(T: int, d: int, bytes_per_elem: float = 2.0) -> Kernel:
    """QK^T + softmax + PV with the (T, T) matrix materialised in HBM (single head)."""
    flops = 2.0 * T * T * d * 2 + 5.0 * T * T
    moved = bytes_per_elem * (3 * T * d + 4 * T * T + T * d)  # Q,K,V in; S out+in, P out+in; O out
    return Kernel(f"naive attention T={T}", flops, moved)


def flash_attention_kernel(T: int, d: int, bytes_per_elem: float = 2.0) -> Kernel:
    """Same FLOPs, but the (T, T) tensor never leaves SRAM: only Q, K, V, O touch HBM."""
    flops = 2.0 * T * T * d * 2 + 5.0 * T * T
    moved = bytes_per_elem * (4 * T * d)
    return Kernel(f"flash attention T={T}", flops, moved)


def time_lower_bound(kernel: Kernel, m: Machine) -> float:
    """Roofline time: max(compute time, memory time)."""
    return max(kernel.flops / m.peak_flops, kernel.bytes / m.bandwidth)


def plot_roofline(m: Machine, kernels: list[Kernel], path: str) -> None:
    """Write a log-log roofline with each kernel placed at (intensity, attainable)."""
    import matplotlib

    matplotlib.use("Agg")
    import matplotlib.pyplot as plt
    import numpy as np

    I = np.logspace(-1, 4, 400)  # (400,)
    roof = np.minimum(m.peak_flops, I * m.bandwidth) / 1e12  # (400,) TFLOP/s
    fig, ax = plt.subplots(figsize=(7.5, 4.8))
    ax.loglog(I, roof, color="k", lw=2, label=m.name)
    ax.axvline(m.ridge_point, color="0.6", ls="--", lw=1)
    ax.text(m.ridge_point * 1.1, roof.min() * 1.5, f"ridge = {m.ridge_point:.0f} FLOP/B", fontsize=9, color="0.4")
    for i, k in enumerate(kernels):
        x = k.intensity
        y = m.attainable(x) / 1e12
        ax.plot(x, y, "o", color=f"C{i % 10}", ms=8)
        ax.annotate(k.name, (x, y), textcoords="offset points", xytext=(6, -12 if i % 2 else 6), fontsize=8)
    ax.set_xlabel("arithmetic intensity (FLOP / byte of HBM traffic)")
    ax.set_ylabel("attainable TFLOP/s")
    ax.set_title("Roofline: memory-bound left of the ridge, compute-bound right")
    ax.grid(True, which="both", alpha=0.3)
    ax.legend(loc="lower right", fontsize=8)
    fig.tight_layout()
    fig.savefig(path, dpi=150, bbox_inches="tight", facecolor="white")
    plt.close(fig)
Full implementation: src/mlbook/systems/flops.py
"""FLOPs accounting for a dense decoder-only Transformer.

Per token, forward pass:

    F_fwd = 2 * P_matmul + 4 * L * h * s          (+ 2 * h * V for the LM head, in P_matmul)

* ``2 * P``: every weight element is used once in a multiply-accumulate (2 FLOPs).
* ``4 L h s``: attention scores Q K^T (2 s h per token per layer) and P V (2 s h).
  Causal masking could halve it; the convention (PaLM, Megatron) counts the full term.

Training = forward + backward = 3x forward, so training FLOPs/token = 6 P + 12 L h s.
With full activation recomputation the forward is done twice: 8 P + 16 L h s (this is
the difference between "model FLOPs" (MFU) and "hardware FLOPs" (HFU)).
"""

from __future__ import annotations

from mlbook.systems.memory_calc import TransformerConfig, count_params


def matmul_params(cfg: TransformerConfig) -> int:
    """Parameters that participate in matmuls (everything except norms and the
    input embedding lookup, which is a gather, not a matmul)."""
    p = count_params(cfg)
    unembed = cfg.vocab * cfg.d_model  # the LM head is a matmul even if tied
    return p["attention"] + p["mlp"] + unembed


def attention_flops_per_token_forward(cfg: TransformerConfig, seq_len: int) -> float:
    """4 * L * h * s: QK^T and PV, forward only, full (non-causal) count."""
    return 4.0 * cfg.n_layers * cfg.d_model * seq_len


def flops_per_token(cfg: TransformerConfig, seq_len: int, mode: str = "train", recompute: bool = False) -> float:
    """FLOPs per token for ``mode`` in {"forward", "train"}.

    train = 3 * forward; with ``recompute`` (full activation checkpointing) = 4 * forward.
    """
    fwd = 2.0 * matmul_params(cfg) + attention_flops_per_token_forward(cfg, seq_len)
    if mode == "forward":
        return fwd
    return (4.0 if recompute else 3.0) * fwd


def training_flops(cfg: TransformerConfig, tokens: float, seq_len: int) -> float:
    """Total training FLOPs ~ (6P + 12 L h s) * tokens."""
    return flops_per_token(cfg, seq_len, "train") * tokens


def six_nd(n_params: float, tokens: float) -> float:
    """The back-of-envelope C = 6 N D (ignores the attention term)."""
    return 6.0 * n_params * tokens

How you'd test it. Ridge point against \(F/BW\); matmul intensity growing with \(M\) and collapsing at \(M=1\); decode-step intensity exactly equal to the batch size; Flash vs naive attention having identical FLOPs and >10× fewer bytes; time_lower_bound equal to the memory term for LayerNorm; flops_per_token equal to \(6N_\text{matmul} + 12Lhs\) and within 10 % of \(6ND\) at short context.

Retype by hand

Symbol File Retype from memory? Target time
Machine.ridge_point, Machine.attainable, time_lower_bound src/mlbook/systems/roofline.py Yes: the roofline calculator 10 minutes
matmul_kernel, decode_step_kernel, naive_attention_kernel, flash_attention_kernel src/mlbook/systems/roofline.py Yes: the byte counts are the point 15 minutes
flops_per_token, matmul_params, attention_flops_per_token_forward src/mlbook/systems/flops.py Yes: FLOPs/token for a Transformer 10 minutes
plot_roofline, layernorm_kernel, six_nd same files Read and understand :

Checks: pytest tests/test_systems_roofline.py tests/test_systems_flops.py -q.

4. Systems view: cost, failure modes, trade-offs

A diagnostic procedure for "this kernel is slow".

  1. Compute \(I\) by hand and compare with the machine's ridge. This tells you which roof you are under and therefore which optimisations are even possible.
  2. Compute time_lower_bound and compare with the measured time. A large gap means you are not even reaching the roof: check occupancy, tile/wave quantisation, launch overhead and synchronisation.
  3. If memory-bound: fuse, quantise, tile into SRAM, increase reuse (batch), or change the algorithm (FlashAttention).
  4. If compute-bound: check you are on tensor cores (dtype and shape multiples), check for partial waves, consider lower precision.
Symptom Likely cause Fix
Tensor-core utilisation ~0, high HBM traffic memory-bound elementwise chain fuse (torch.compile, custom kernel)
Big GEMM at 40 % of peak K too small, or M/N not multiples of 64/128 pad shapes; pick better tile sizes
Decode step much slower than \(wP/BW\) kernel launch overhead, Python in the loop CUDA graphs, fewer/fused kernels
Throughput drops at one specific batch size wave quantisation (a partial last wave) choose batch/tile so tiles ≈ multiple of SM count
Host→device copy dominates pageable memory, synchronous copies pinned buffers, async copies on a side stream
Attention dominates at long context \(O(T^2)\) traffic in naive attention FlashAttention; then it is \(O(T^2)\) compute only
Multi-GPU step slow, kernels fine collective on the wrong link keep TP on NVLink; check topology with the vendor tools

The memory wall as a trend. Compute per dollar has historically grown much faster than bandwidth per dollar, so \(I^\star\) rises with each generation. A model architecture that was compute-bound two generations ago can be bandwidth-bound today with no code change. Practical implications: (i) arithmetic-reducing tricks (sparsity, low-rank) often fail to deliver wall-clock wins because they do not reduce bytes; (ii) techniques that reduce bytes (quantisation, GQA/MQA, KV compression, fusion) keep paying off; (iii) the value of on-package memory bandwidth (HBM generations) is often the real story behind a new accelerator's speed-up on inference.

Where cost actually goes. For training, \(\text{GPU-hours} = 6ND/(F_\text{peak}\cdot\text{MFU})\), so hardware choice and MFU are multiplicative; for serving, cost per token is \(\propto wP/(B \cdot BW)\) in the memory-bound regime, i.e. bandwidth and bytes-per-weight are the cost drivers, not FLOPs. That asymmetry (training pays for FLOPs, serving pays for bandwidth) is a genuinely staff-level observation and a good thing to say out loud.

5. In production

Berkeley: the Roofline model (2009)

Williams, Waterman and Patterson introduced the roofline as a "visually intuitive performance model" so that kernel authors could see, in one plot, whether to optimise memory traffic or arithmetic. It became the standard first slide of every performance review because it turns a vague "is this fast?" into a specific "which roof are we under, and how far below it?". Source: Williams, S., Waterman, A., Patterson, D., "Roofline: An Insightful Visual Performance Model for Multicore Architectures", CACM 52(4), 2009.

Stanford: FlashAttention: an IO-aware algorithm (2022–2023)

Problem: attention was memory-bound because the \(T\times T\) score matrix round-tripped through HBM. Built: tiling plus online softmax so the score tile lives in SRAM, making HBM traffic linear in \(T\) for the same FLOPs; FlashAttention-2 improved work partitioning and reduced non-matmul FLOPs. The framing (count HBM accesses, not FLOPs) is the transferable lesson, and it is the same lesson the roofline teaches. Sources: Dao et al., "FlashAttention: Fast and Memory-Efficient Exact Attention with IO-Awareness", NeurIPS 2022, arXiv:2205.14135; Dao, "FlashAttention-2", 2023, arXiv:2307.08691.

Google: TPU v4 and the case for a dedicated fabric (2023)

Google's TPU v4 paper describes optically reconfigurable interconnect (OCS) between chips in a pod, which lets the topology be reshaped per job, and reports performance/Watt advantages over contemporary GPU systems for their workloads. The architectural thesis is the systolic array plus a purpose-built fabric: maximise reuse inside the MXU, and do not make the network a general-purpose PCIe tree. Source: Jouppi et al., "TPU v4: An Optically Reconfigurable Supercomputer for Machine Learning with Hardware Support for Embeddings", ISCA 2023, arXiv:2304.01433; and Jouppi et al., "In-Datacenter Performance Analysis of a Tensor Processing Unit", ISCA 2017, arXiv:1704.04760 for the original systolic-array analysis, which is itself a roofline study.

OpenAI: Triton (2021)

Problem: writing CUDA for every fused kernel is expensive, but PyTorch's op-by-op execution leaves memory-bound performance on the table. Built: Triton, a Python-embedded language where you write a tile program and the compiler handles vectorisation, shared-memory staging and scheduling. It is now the backend for many torch.compile-generated kernels, i.e. the fusion argument in §2.6, industrialised. Source: Tillet, Kung & Cox, "Triton: an intermediate language and compiler for tiled neural network computations", MAPL 2019, and the Triton documentation.

NVIDIA: Hopper (H100), and why the ridge moved

H100 SXM's published dense BF16 tensor-core throughput (989 TFLOP/s with the sparsity feature off) against 3.35 TB/s of HBM3 puts its ridge at ~295 FLOP/byte, versus ~156 for the A100. The same model, unchanged, is therefore more likely to be memory-bound on newer hardware, which is the quantitative reason FlashAttention, quantisation and GQA became mandatory rather than optional in the H100 generation. Source: the NVIDIA H100 datasheet, which prints 1,979 TFLOP/s BF16 with sparsity, and the A100 80 GB datasheet.

6. Interview questions and strong answers

Explain the roofline model and place attention, matmul, LayerNorm and LLM decode on it.

Attainable performance is \(\min(F_\text{peak}, I\cdot BW)\) with \(I\) = FLOPs per byte moved; the ridge \(F_\text{peak}/BW\) is ~295 FLOP/byte on an H100. A large prefill GEMM has \(I\) in the thousands: compute-bound, on the flat roof. FlashAttention is also compute-bound because it keeps the \(T\times T\) tile in SRAM (\(I \approx T/2 \approx 2000\) at \(T\)=4096), whereas naive attention writes and re-reads that matrix and lands at \(I \approx d/2 \approx 60\): same FLOPs, 30× less intensity. LayerNorm is \(I\approx2\): pure bandwidth. LLM decode has \(I\) equal to the batch size, so batch-1 decode sits at \(I=1\), 295× left of the ridge. Staff follow-up: "what does the roofline not tell you?" It is an upper bound assuming perfect overlap and full occupancy; it ignores launch overhead, cache effects between the extremes, tail waves and synchronisation, so a kernel can be far below the roof for reasons the model does not express.

Why does padding the vocabulary from 50,257 to 50,304 make training faster?

The LM-head GEMM's N dimension is the vocabulary. Tensor cores consume fixed tiles and cuBLAS decomposes the GEMM into tiles of 64–128; 50,257 is not a multiple of 8, so it can fall off the fast tensor-core path entirely, and even if not, the final tile is ragged and the last wave of thread blocks runs at partial occupancy. Padding to 50,304 = 128 × 393 makes every tile full. The extra logits are masked out or never selected, so quality is unchanged. Follow-up: "where else does this bite?" Head dimension and \(d_{ff}\) not multiples of 64, odd batch sizes in serving (hence padding to bucketed batch sizes for CUDA graphs), and sequence lengths that produce partial tiles in attention.

You have a fused kernel idea that removes 30 % of the FLOPs from a LayerNorm. Worth it?

No, LayerNorm sits at \(I \approx 2\), roughly 150× left of the H100 ridge, so its runtime is \(M/BW\) and is unchanged by removing arithmetic. What would help is removing memory traffic: fuse the norm with the preceding residual add and the following projection so the tensor is read once instead of three times, or keep it in registers. This is the general rule: left of the ridge, optimise bytes; right of the ridge, optimise FLOPs. Follow-up: "how would you verify before writing the kernel?" Compute \(I\) and time_lower_bound, then measure the current kernel; if it is already at the bandwidth bound the only win available is fusion.

Walk me through the memory hierarchy and where host↔device transfers fit.

Registers (~10s of TB/s) → shared memory/L1 (~10 TB/s) → L2 (tens of MB, several TB/s) → HBM (80 GB, 3.35 TB/s) → NVLink to a peer GPU (~450 GB/s per direction) → PCIe to the host (~64 GB/s) → InfiniBand to another node (50 GB/s per 400 Gb/s port). Roughly an order of magnitude per step. Host transfers must be rare, pinned and asynchronous: pinned memory lets the DMA engine transfer without a bounce buffer and lets the copy overlap compute on a separate stream; a pageable synchronous copy in the training loop is a hard stall that shows up as a gap in the profiler. Follow-up: "when would you deliberately go to host memory?", KV-cache offload for very long contexts or high concurrency, optimizer-state offload (ZeRO-Offload) when memory-bound rather than bandwidth-bound; in both cases you are trading a 50× slower link for capacity, so it only wins when the alternative is not running at all.

How do you compute the FLOPs of a training step, and what do people get wrong?

\(6N + 12Lhs\) per token: \(2N\) forward (one multiply + one add per weight), \(\times 3\) for forward+backward, plus \(4Lhs\) forward for \(QK^\top\) and \(PV\). The common errors: counting the input embedding as FLOPs (it is a gather), forgetting the LM head (a real GEMM, and large when the vocabulary is 128k), forgetting the attention term entirely (14 % for 7B at \(s\)=4096, much more at long context), and conflating MFU with HFU by counting recomputed forwards. Follow-up: "what about MoE?" Use active parameters per token for FLOPs but total parameters for memory; that divergence is the entire economic argument for MoE.

What do CUDA graphs buy, and what do they cost?

Each kernel launch is a few microseconds of CPU work; a decode step is hundreds of small kernels that each run for microseconds, so launch overhead and CPU jitter can dominate. A CUDA graph records the step's whole kernel DAG once and replays it with a single submission. The cost is rigidity: shapes, pointers and control flow must be static, so serving engines pad to a fixed set of batch sizes and pre-allocate KV blocks, and any dynamic shape forces a re-capture. Follow-up: "is it worth it for training?" Much less, because training steps have large kernels where launch overhead is a rounding error; it is a small-batch inference optimisation.

7. Exercises

  1. ★ Compute the arithmetic intensity and roofline time on an H100 for a \((1 \times 4096) \times (4096 \times 4096)\) bf16 matmul, and for the same with \(M = 512\).

    Solution

    \(M=1\): FLOPs \(3.36\times10^7\), bytes \(2(4096 + 4096^2 + 4096) = 33.6\) MB, \(I \approx 1.0\), time \(= 33.6\text{MB}/3.35\text{TB/s} = 10\,\mu\)s, memory-bound. \(M=512\): FLOPs \(1.7\times10^{10}\), bytes \(\approx 42\) MB, \(I \approx 410\), compute-bound, time \(= 1.7\times10^{10}/9.89\times10^{14} = 17\,\mu\)s. 512× the work for 1.7× the time.

  2. ★ A kernel achieves 120 TFLOP/s on an H100 at \(I = 40\). Is it well optimised?

    Solution

    At \(I=40\) the roof is \(40 \times 3.35\times10^{12} = 134\) TFLOP/s (memory-bound side). It is at 90 % of its attainable roof, so it is well optimised for its intensity, the remaining win is algorithmic (raise \(I\)), not micro-optimisation.

  3. ★★ Using roofline.py, find the sequence length at which naive attention's intensity drops below LayerNorm's, at \(d = 128\). Then confirm FlashAttention's never does.

    Solution

    \(I_\text{naive} \to \frac{4T^2d}{2(4T^2 + 4Td)}\), which decreases toward \(d/2 = 64\) as \(T\) grows and stays there, so it never falls below LayerNorm's 2, but it is already ~60 at \(T=4096\), i.e. 5× left of the ridge, which is enough to make it the bottleneck. \(I_\text{flash} = T/2\) increases with \(T\). The lesson: naive attention's intensity is capped by the head dimension; Flash's grows with sequence length.

  4. ★★ Compute the FLOPs and the training time for Llama-3-8B on 15T tokens at 40 % MFU on 1024 H100s, then recompute assuming full activation recomputation and explain which number you would put in a capacity plan.

    Solution

    \(6ND = 6 \times 8.03\times10^9 \times 1.5\times10^{13} = 7.2\times10^{23}\) FLOPs; \(/(1024 \times 9.89\times10^{14} \times 0.4) = 1.78\times10^6\) s ≈ 20.6 days. With full recompute the hardware executes 4/3 as much, so if MFU stays 40 % the wall-clock is the same 20.6 days but HFU is 53 %; if instead the hardware is saturated at 40 % HFU, the wall-clock becomes 27.5 days. Put the MFU-based number in the plan and state the recomputation assumption explicitly, this ambiguity is exactly why MFU is the standard.

  5. ★★★ Extend roofline.py with a Machine for a hypothetical accelerator with 2× the H100's compute and the same bandwidth. Recompute the ridge, and determine which of the seven kernels in figures/part14_roofline.py change side. What does this predict about the next hardware generation?

    Solution

    Ridge doubles to ~590 FLOP/byte. The decode-B=256 kernel (\(I\)=256), the decode matmul at B=64 (\(I\)=62) and naive attention (\(I\)=63) stay memory-bound; the prefill GEMM (\(I\)=1638) and FlashAttention (\(I\)=2068) stay compute-bound but now achieve 2×. Prediction: doubling FLOPs with flat bandwidth only helps the already-compute-bound kernels, so serving throughput at small batch does not improve at all, which is why real generations ship HBM upgrades alongside compute, and why bandwidth-reducing techniques (quantisation, GQA) keep their value across generations.

References
